Lightweight but extremely rugged: steel pedestal and arm, and dual ball-bearings. The Evolution combines design, performance, and reliability with the right features and benefits for today's customers. All Evolution series reels have a narrow and lightweight design; includes hose, hose stop, and a 2.5f connecting hose. Air & Water Low Pressure 300 psi (21 bar) for delivery of air, water, and Anti-freeze. - Superb corrosion resistance - Superior structural design and stability - Fully ported shaft and pressure balanced swivel - High quality, long life power spring - Spool mounted on dual ball-bearings - Rectangular hose guide outlet with rollers - Multi-Positioning outlet arm



Features

• Air & Water Low Pressure 300 psi (21 bar) for delivery of air, water, and Anti-freeze.
• Eight-position latching mechanism.
• Fluid compatibility for multiple applications.
• Easy maintenance and service.
• Easy on-site tension adjustment.
• Easy installation mounting and accessories.
• Fluid inlet - 1/" NPT (F) swivel.
• Fluid outlet - 1/2" NPT (F) swivel.
• Outlet thread - 1/4"NPT (M).
• Wetted materials - Nickle plated steel and Buna-N™.



Technical

Weight approx.	44	lbs
Power supply	Air	V/Hz/A
Dimensions (L x W x H)	18 x 6-1/2 x 20	inch



Options

44-2140-011	Evolution Air/Water Reel - 50' x 1/2"	$535.00	Add to cart
44-2230-002	Mounting Channel I-Beam Bracket Kit	$91.00	Add to cart
44-2230-003	Mounting Channel - 1 Reel	$95.00	Add to cart
44-2230-004	Mounting Channel - 2 Reels	$120.00	Add to cart
44-2230-005	Mounting Channel - 3 Reels	$152.00	Add to cart
44-2230-007	Mounting Channel - 5 Reels	$216.00	Add to cart
44-2230-014	Mounting Channel Plate	$48.00	Add to cart
44-8136-050	Hose Assembly 50' x 3/8" Low Pressure	$125.00	Add to cart
