The MBUSA PicoScope 4425A Diagnostic Kit is designed specifically to help technicians identify a wide range of vehicle electrical and electronic systems faults through accurate and efficient voltage and current. It does not include the extra accessories built into the MBUSA NVH (733-KP543), Pressure Transducer (733-KP542) or Optical Sensor (733-PQ316) kits.
The MBUSA Diagnostic kit is powered by the PicoScope 4425A 4-channel oscilloscope which features an industry-leading 400MS/s sampling rate, 250MS of memory and our PicoBNC+ intelligent lead connection technology. It is ideal for viewing signals from the ignition system, sensors, actuators and communications networks including CAN and FlexRay.
The PicoScope 4425A oscilloscope connects to a PC via USB connection for user control and high-resolution waveform display. Our XENTRYPicoScope operating software provides many powerful tools for waveform analysis and allows users to access a built-in database of Guided Tests and reference waveforms.
NOTE: The PicoScope 4425A 4-Channel Automotive Oscilloscope in this kit is not compatible with the Mercedes-Benz XENTRY diagnostic software. It requires PicoScope user software (downloadable free) and a desktop or laptop running a minimum of Windows 10.
TYPICAL APPLICATIONS:
- Test vehicle components/systems with minimal teardown.
- Find troublesome intermittent faults.
- Investigate issues with no, multiple, or misleading fault codes.
- Diagnose charging and starting faults.
- Trace problems with actuators not monitored by the ECU.
- Identify mechanical problems.
- Develop objective data for manager/customer discussions.
- Part of proven NVH solution.
Support Documentation
Features
- Complete Kit Contents on support documentation.
Technical
| Weight approx. | 21 | lbs |
| Dimensions (L x W x H) | 25 x 25 x 15 | inch |
