The Pico Standard NVH Diagnostic kit from Pico Technology is a cost-effective answer to the many NVH problems facing technicians today. This Kit will allow you to measure vibrations on 3 axes (X, Y and Z) or optionally, to measure vibration or sound on a single axis at an additional location on a vehicle. The software provides a real-time diagnosis to the technician, in the form of either: a bar graph, a frequency chart, a 3D frequency chart, RPM order, road speed view or a time domain view. The ability to start the recording before a road test and playback and analyze the recording back in the shop, ensures that the driver's attention remains on the road. Plus, recordings can be saved to your computer to share or analyze later.

TYPICAL APPLICATIONS:

Cabin vibrations at speed

Engine vibrations throughout the entire RPM range

Clutch judder or vibration

Transmission and bearing whine

Auxiliary drive noise

Steering vibrations

KIT INCLUDES:

(2) 3 Output NVH interface

(2) 3-Axis accelerometer

(2) Magnetic mounting for accelerometer

(2) Microphone for NVH kit

(2) 3 Meter extension cable for the accelerometer or microphone

(1) BNC cable (50cm) – blue

(1) BNC cable (50cm) – red

(1) BNC cable (50cm) – green

(1) BNC cable (50cm) – yellow

(1) Carry case



Support Documentation

• PQ129-PicoNVHStandardKit-ContentsList.pdf



Technical

Dimensions (L x W x H)	11 X 10 X 4	inch
Weight approx.	4	lbs
