The pneumatic suction wagon is a special service unit for motor car repair or mover shops and will be especially use for the removal of used engine and gear oils from vehicle motors as well as of other non aggressive liquids up to danger class A III.



Features

• Solid chassis provided with two driving and two steering castors and a shift lock. An 60 l tank with overflow indicator made of stainless steel is screwed tight to the frame.
• Pneumatic driven diaphragm pump.
• On the control panel there are the combination of the control valves for changing the flow of the pump and also a vacuum gauge.
• Suction hose DN 16, 2,2 m long with special adapter which will be use for the probes.
• Air pressure hose DN 6, 5 m long with connecting fittings.
• A set of probes (∅ 5,4 mm; ∅ 5,6 mm and ∅ 7,5 mm all probes 670 mm long).
• For oil change at a hydraulic ramp a height adjustable collecting pan can be installed on the 60 l reservoir. Art.- No.: 40 403 110.
• Dimensions 60 l (B x H x L) 615 x 885 x 630 mm
• TypeDiaphragm pump • material of diaphragmBuna N • pump capacity *max. 10 l/min • medium lubricating oil • dirt level max. 1,5 mm.
• Max. temperature+ 80 °C.
• Working pressure 7 bar.
• Air consume max. 25,5 m3.



Technical

Weight approx.	132	lbs
Dimensions (L x W x H)	249 x 243 x 349	inch
