18k 4 Post 23O"wb Mercedes

USD $17,081.00

39-SM18EL2MB
Rotary Lift

Click to see additional Options / Models / Accessories Available
Accessories

Request a call



Click to view California Proposition 65 warning



Heavy-duty surface-mounted drive on 4-post lift.

Ideal 4 Post Lift for Sprinter Vans



Features

  • Spotting friendly, this is especially important if you're the only tech working on the vehicle. No need to climb in or down from high places constantly to make sure everything is correct. You're already there once you're up on the lift platforms.
  • Offers quick setup for undercarriage repairs. Set up your heavy-duty shop with a 4-post lift drive-through bay. Repairs could be made, drive off to test repair and if need be drive right back on.
  • Air Filter/Regulator/Lubricator.
  • Adjustable latch bars.
  • Single piece non-welded runway with tracks for rolling jacks.



Technical

Lifting height 77-3/4 inch
Lifting/lowering time approx. 66 s
Weight approx. 3887 lbs
Color Auto Haus Blue
Track length 230 inch
Track width 22 inch
Power supply 208-240 / 60 / 20 V/Hz/A
Dimensions (L x W x H) 261 x 24 x 37 inch
Load carrying capacity 18,000 lbs



Accessories

39-FA2259BK Air/Eletric Utlity Box with FRL for 4 Post $717.00 Add to cart
39-FA2260BK Air/Eletric Utlity Box for 4 Post $501.00 Add to cart
