The 6:1 ratio Tiger HP® pump can service as many as six simultaneous dispense points or transfer oil to distances up to 700 feet. Maximum simultaneous dispense points @ 1.5 gal/m (5.7 l/m) per dispense point. Note: pumping distance and pipe diameter will affect dispensing performance. The Tiger HP® air motor features a precision air valve mechanism with dual valve ports for improved high-speed breathing. It also contains a positive trip detent spool mechanism that eliminates stalling (blowing air) by preventing the pump from stopping between strokes. It has a simple yet durable construction with all internal parts lubricated at the factory using a life-tested synthetic grease. The Tiger HP® pumping assembly features a stainless pump rod for superior wear and corrosion resistance. The pump's exterior is constructed from aircraft-grade extruded aluminum for outstanding strength and reliability. The pump also has high-quality seals and is designed for long-term durability and ease of service. It is equipped with internal pressure relief to protect the system from thermal expansion.



Features

• Operating air pressure range: 40–150 PSI (3–10 bar).
• Pump delivery with SAE 10W30 oil, 68º F (20º C), 100 psi (7 bar) air pressure and free flow 16 gal/m (61 l/m).
• Air consumption 100 psi (7 bar) and 8 gal/m (30 l/m) 59 SCFM.
• Max fluid stall pressure @150 psi (10 bar) air 870 PSI (60 bar).
• Wetted materials - Carbon steel, Buna-N™ Stainless steel, Nickel plated steel, Nylon, Ultrathane, and Viton.
• 31 Cycles per Gal.
• Air Inlet - 3/8” NPT (F).
• Fluid Inlet - 1” NPT (F) 1-1/2” NPT (M).
• Fluid Outlet - 3/4” NPT(F).
• Effective Air Piston diameter - 3.2” (81 mm).



Technical

Dimensions (L x W x H)	25.72 H x 5.82 W	inch
Power supply	Air	V/Hz/A
Weight approx.	39	lbs



Options

44-4410-056	Tiger Pump Hose Connecting Kit	$172.00	Add to cart
44-4411-008	Wall Mount Bracket for LYNX, Panther HP and Tiger pumps	$118.00	Add to cart



Accessories

44-3230-018	In-Line Hand Operated Valve for Air - 1/4" - 580 PSI	$13.00	Add to cart
44-3230-019	In-Line Hand Operated Valve for Air - 3/8" - 580 PSI	$17.00	Add to cart
44-3230-020	In-Line Hand Operated Valve for Air - 1/2" - 580 PSI	$18.00	Add to cart
44-3230-021	In-Line Hand Operated Valve for Air - 3/4" - 580 PSI	$23.00	Add to cart
44-3230-022	In-Line Hand Operated Valve for Air - 1" - 580 PSI	$36.00	Add to cart
