The COP and signal probe is the easiest and fastest non-intrusive way to check coil-on-plug ignition coils and spark plugs.

Like distributors, spark plug wires are starting to disappear from cars. With the new COP ignition systems, the ignition coils are connected directly to the spark plugs — eliminating the need for the spark plug wires. With no high-voltage spark wires, a COP probe is required to be able to pick up the secondary ignition waveform.

This lead is fitted with a PicoBNC+ interface, allowing it to be recognized by the software for auto-configuration. The lead requires a PicoScope featuring the PicoBNC+ such as the 4225A or 4425A.



Features

• Find misfires fast
• Displays scope patterns of the secondary, faster than scoping the primary
• Can also be used to investigate injectors and other inductive actuators
• Flexible design allows for easier access to hard-to-reach components
• No batteries required



Technical

Weight approx.	3 lbs	lbs
Power supply	Powered from PC USB connection	V/Hz/A
Dimensions (L x W x H)	12x8x2.53 lbs	inch
