These cord reels are designed for use in dealerships. *Multi- positioning Outlet Arm – provide ease of changing from ceiling to base mount: five positions for any application and mounting configuration. *Easy spring tension can be adjusted on site by adding or removing cord wraps easily from the reel. *Industrial grade collector ring, replaceable carbon brushes, and brass transfer rings



Features

• Adjustable ball stop allows user to set height of the retracting cord
• 5.5’ power inlet cord with grounded plug
• SJTO Cord. Cord is rated to 300 volts and has a temperature range of –20ºC to 60ºC
• Indoor use only - Dry Location
• Cord Length 40' (12.9 m)
• Gauge 12/3 SJTO
• Inlet Cord 5.5' (1.67 m) 12/3 SJTO
• Plug NEMA 5-20P Grounded
• Amps 20
• Receptacle NEMA 5-20R GFCI Duplex



Technical

Dimensions (L x W x H)	12.5" X 9 X 13.25	inch
Power supply	115V / 60Hz / 20A	V/Hz/A
Weight approx.	30	lbs
